YUSH CARTON MACHINE COMPANY
To supply customers, most suitable machine & best quality service, at most reasonable cost

|
| Place of Origin: | China |
| Brand Name: | YUSH |
| Certification: | CE |
| Model Number: | BFY-NC |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 100,000~500,000 per set |
| Packaging Details: | well packaged to loaded in container |
| Delivery Time: | 30~60 working days |
| Payment Terms: | T/T |
| Supply Ability: | 5 sets per month |
| Name: | Used NC Thin Blade Slitter Scorer | Type: | Automatic |
|---|---|---|---|
| Max Width: | 2200mm | Min Width: | 1100mm |
| Knife And Die: | 5-slitter 8-scorer | Speed: | 100~200m/min |
| Control: | Full Computer | Use: | Computer-control Slitting And Creasing Corrugated Cardboard |
| High Light: | second hand slitter scorer,second hand slitter scorer machine,computer servo control slitter scorer |
||
Technical Parameters:
1) Memory of 999 orders, non-stop changeover or manual change over can be realized.
2) Change over quickly, within 3 to 8 seconds. Application of two machines can realize non-speed reduction changeover.
3) Automatic synchronize with the corrugated line and can also get in line with manufacture management system. High compatibility.
4) High quality imported industry computer and PLC equipped composing the CNC system.
5) There are three types of scores: concave-convex(single wall), concave-convex(double wall) and convex-flat, which can also be alternated with electrical system Scoring can also be computer controlled with fine scoring results.
6) Thin tungsten steel alloy blade, sharp and long life of over 8 million meters.
7) Computer controlled auto grinding and manual grinding also applicable. Alternative grinding the blade when slitting the board, it can increase efficiency.
8) Imported synchronous belt applied for conveying with higher precision, longer life and lower noise.
Technical Parameters:
| Max Effective Width | 1100~2500mm |
| Slitting Knife | 4~6pcs |
| Min Slitting Distance | 200mm |
| Scoring Wheel | 6~10pairs |
| Min Scoring Distance | 0 |
| Design Speed | 150~250m/min |
| Working Speed | 120~220m/min |
used Corrugator Line, 3/5/7-layer, various flute type, low-medium-high speed
1) 2/3/5/7-layer Corrugated Cardboard Production Line consists of the following machines, Electrical or Hydrualic Shaftless Mill Roll Stand, Automatic Splicer, Single Preheater, Fingerless type Single Facer Corrugator, Overhead Conveyor Bridge, Duplex or Triplex Preheater, Single or Duplex Gluer, Double Facer, NC Thin Blade Slitter Scorer, NC Rotary Cut-off, Up or Down Conveyor & Stacker, etc.
2) Kraft Paper Reel to be corrugated and glue by Corn Starch Gum, continuously produce, slit, crease & cut to 2/3/5/7-layer Corrugated Cardboard Sheet, and then conveyor, stack and output.
3) The production line has rational structure design, advanced producing flow, high efficiency, strong batch adjustability, easy operation, etc. good work conditions.
4) It is the ideal and perfect equipment for corrugated cardboard and carton box factories.
Technical Parameters:
| Model | 3/5/7-layer |
| Max Effective Width | 1100~2500mm |
| Design Speed | 100~250m/min |
| Heating Method | Steam Heating |
| Working Speed | 80~220m/min |
| Workshop Suggested | 3000~5000sqm |
| Customer-owned Parts | Steam Boiler, Pipeline, Wireline, Air Compressor, etc. |
Machine List:
| Item | Model | WJ-I | WJ-II | WJ-III |
| Description | 3-layer | 5-layer | 7-layer | |
| 1 | Shaftless Paper Roll Stand | 3 | 5 | 7 |
| 2 | Track Rail & Paper Roll Trolley | 6 | 10 | 14 |
| 3 | Auto Splicer | 3 | 5 | 7 |
| 4 | Single Preheater | 2 | 4 | 6 |
| 5 | Single Facer Corrugator | 1 | 2 | 3 |
| 6 | Overhead Conveyor Bridge | 1 | 1 | 1 |
| 7 | Multiple Preheater | 1 | 1 | 1 |
| 8 | Gluer | 1 | 1 | 1 |
| 9 | Double Facer | 1 | 1 | 1 |
| 10 | Thin Blade Slitter Scorer | 1 | 1 | 1 |
| 11 | NC Helical-knife Cut-off | 1 | 1 | 1 |
| 12 | Conveyor Stacker | 1 | 1 | 1 |
| 13 | Glue Kitchen System | 1 | 1 | 1 |
| 14 | Internal Steam Heating System | 1 | 1 | 1 |
| 15 | Electricla Control System | 1 | 1 | 1 |
YUSH CARTON MACHINE, your best supplier for Corrugated Cardboard & Carton Box Making Machines
Sincerely, welcome you to join our cooperator team, we shall repay you with top-notch products and perfect services.
