YUSH CARTON MACHINE COMPANY
To supply customers, most suitable machine & best quality service, at most reasonable cost
 |
| Place of Origin: | China |
| Brand Name: | YUSH |
| Certification: | CE |
| Model Number: | SMY |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 40,000~50,000 per set |
| Packaging Details: | well packaged to loaded in container |
| Delivery Time: | 15~30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 30 sets per month |
| Condition: | New | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Function: | Multi-function Digital Printing | Warranty: | One Year |
| Size: | Customized | Speed: | Customized |
| Color: | Customized | Voltage: | Made To Customer Request |
| High Light: | corrugated die cutting machine,flat bed die cutting machine |
||
Multi-function Digital Printing Machine
Technical Parameters:
| Printing Nozzle | 2~8 |
| Max Printing Area | 2500*1300mm |
| Material Thickness | 0~100mm |
| Ink Type | UV Ink |
| Color | C, M, Y, K, LC, LM, W, V (optional) |
| Ink Bucket | 2.5L/color |
| Ink Supply | Automatic negative pressure ink supplying system |
| Ink Inspect | Automatic ink inspecting system |
| RIP Software | Photoprint (or Print Factory, or Onxy) |
| Printing Material | Paper, cardboard, carton, acrylic, aluminum, tile, glass, wood, PC, TPU, leather, PVC, etc. |
| Material Suction | 4-area vacuum suction |
| Picture Type | TIFF, JPEG, PDF, EPS, PNG, AI, BMP, etc. |
| Dimension | 4155*1980*1506mm |
| Weight | 1250kg |
| Voltage | 220V, 50/60Hz, Single-phase |
| Power | 8kw |
| Lifting Function | Auto inspect thickness, auto lifting |
| Operation System | Win7, USD2.0/3.0, 500G HD, ATI VGA, 8G RAM, Intel I5 CPU |
| Workshop Requirement | Independent, clean, low dust, less light, good ventilation, temperature 15~28oC, humidity 40~60%RH |
| Ventilation Equipment | overhead exhaust fan with a displacement of 600cfm |
| Printing Speed | High Speed 45m2/h Normal Production 30m2/h High Precision 23m2/h |
