YUSH CARTON MACHINE COMPANY
To supply customers, most suitable machine & best quality service, at most reasonable cost

|
| Place of Origin: | China |
| Brand Name: | YUSH |
| Certification: | CE |
| Model Number: | BFY-NC |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 50,000~80,000 per set |
| Packaging Details: | well packaged to loaded in container |
| Delivery Time: | 30~60 working days |
| Payment Terms: | T/T |
| Supply Ability: | 15 sets per month |
| Condition: | New | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Function: | Computer-control Slitting And Creasing Corrugated Cardboard Line | Warranty: | One Year |
| Size: | Customized | Speed: | Customized |
| Color: | Customized | Voltage: | Made To Customer Request |
| High Light: | slitter scorer corrugated,thin blade slitter scorer machine |
||
Technical Parameters:
1) Memory of 999 orders, non-stop changeover or manual change over can be realized.
2) Change over quickly, within 3 to 8 seconds. Application of two machines can realize non-speed reduction changeover.
3) Automatic synchronize with the corrugated line and can also get in line with manufacture management system. High compatibility.
4) High quality imported industry computer and PLC equipped composing the CNC system.
5) There are three types of scores: concave-convex(single wall), concave-convex(double wall) and convex-flat, which can also be alternated with electrical system Scoring can also be computer controlled with fine scoring results.
6) Thin tungsten steel alloy blade, sharp and long life of over 8 million meters.
7) Computer controlled auto grinding and manual grinding also applicable. Alternative grinding the blade when slitting the board, it can increase efficiency.
8) Imported synchronous belt applied for conveying with higher precision, longer life and lower noise.
Technical Parameters:
| Max Effective Width | 1100~2500mm |
| Slitting Knife | 4~6pcs |
| Min Slitting Distance | 200mm |
| Scoring Wheel | 6~10pairs |
| Min Scoring Distance | 0 |
| Design Speed | 150~250m/min |
| Working Speed | 120~220m/min |
YUSH CARTON MACHINE, your best supplier for Corrugated Cardboard & Carton Box Making Machines
Sincerely, welcome you to join our cooperator team, we shall repay you with top-notch products and perfect services.
